Code 61 & Code 62 Union and Blanking Plates

STEP Files

A 3d button beside a part number indicates that a 3D model is available for that product. Click the button to view and interact with the 3D model.

Code 61 Union and Blanking Plates
Figure 1 O-Ring Union	Figure 2 Companion Blanking	Figure 3 Companion Union	Flange Size	A	S	GG	HH	L	W	T
3365-12	1205-12	1207-12	0.75	0.75	13/32	0.875	1.875	2.63	1.75	0.50
3365-16	1205-16	1207-16	1.00	1.00	13/32	1.031	2.062	2.81	2.00	0.50
3365-20	1205-20	1207-20	1.25	1.25	15/32	1.188	2.312	3.13	2.50	0.50
3365-24	1205-24	1207-24	1.50	1.50	17/32	1.406	2.750	3.69	3.00	0.50
3365-32	1205-32	1207-32	2.00	2.00	17/32	1.688	3.062	4.00	3.50	0.50
3365-40	1205-40	1207-40	2.50	2.50	17/32	2.000	3.500	4.50	4.00	0.50
3365-48	1205-48	1207-48	3.00	3.00	21/32	2.438	4.188	5.31	5.00	0.50
3365-56	1205-56	1207-56	3.50	3.50	21/32	2.750	4.750	6.00	5.00	0.50
3365-64	1205-64	1207-64	4.00	4.00	21/32	3.062	5.125	6.38	6.00	0.50

Code 62 Union and Blanking Plates
Figure 1 O-Ring Union	Figure 2 Companion Blanking	Figure 3 Companion Union	Flange Size	A	S	GG	HH	L	W	T
3366-12	1881-12	1859-12	0.75	0.75	13/32	0.937	2.000	2.81	2.00	0.50
3366-16	1881-16	1859-16	1.00	1.00	15/32	1.093	2.250	3.19	2.50	0.50
3366-20	1881-20	1859-20	1.25	1.25	17/32	1.250	2.625	3.75	3.00	0.50
3366-24	1881-24	1859-24	1.50	1.50	21/32	1.437	3.125	4.44	3.50	0.75
3366-32	1881-32	1859-32	2.00	2.00	25/32	1.750	3.812	5.25	4.00	0.75

Code 61 Companion Union Plates

Code 61 Companion Union Plates
Part Number	Flange Size	A	Z	GG	HH	T
3367-12-123d	0.75	0.75	3/8"-16	0.875	1.875	1.00
3367-16-163d	1.00	1.00	3/8"-16	1.031	2.062	1.00
3367-20-203d	1.25	1.25	7/16"-14	1.188	2.312	1.25
3367-24-243d	1.50	1.50	1/2"-13	1.406	2.750	1.50
3367-32-323d	2.00	2.00	1/2"-13	1.688	3.062	1.50
3367-40-403d	2.50	2.50	1/2"-13	2.000	3.500	1.50
3367-48-483d	3.00	3.00	5/8"-11	2.438	4.188	1.50
3367-56-563d	3.50	3.50	5/8"-11	2.750	4.750	1.50
3367-64-643d	4.00	4.00	5/8"-11	3.062	5.125	1.50

Code 62 Companion Union Plates
Part Number	Flange Size	A	Z	GG	HH	T
3368-12-123d	0.75	0.75	3/8"-16	0.937	2.000	1.00
3368-16-163d	1.00	1.00	7/16"-14	1.093	2.250	1.25
3368-20-203d	1.25	1.25	1/2"-13	1.250	2.625	1.50
3368-24-243d	1.50	1.50	5/8"-11	1.437	3.125	1.50
3368-32-323d	2.00	2.00	3/4"-10	1.750	3.812	1.50
